Inductive proximity sensor

Inductive high temperature proximity sensor

 Maximum operating temperature is 230℃

 Stainless Steel Housing 1.4305 St Stl

 Different structures and sizes, reliable product quality, stable temperature drift performance

Industry application：Automobile industry / Packaging industry / Smart storage / Metallurgical Industry / Petrochemical / Printing industry / Machine tool industry / Textile industry / Food Industry / Factory automation

Basic Parameters

  • M8
  • M12
  • M18
  • M30
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
POH-M0802N1-DF3-140 M8 2mm Flush NPN.NO 45mm Cable,2m,3-wire
POH-M0802N2-DF3-140 M8 2mm Flush NPN.NC 45mm Cable,2m,3-wire
POH-M0802P1-DF3-140 M8 2mm Flush PNP.NO 45mm Cable,2m,3-wire
POH-M0802P2-DF3-140 M8 2mm Flush PNP.NC 45mm Cable,2m,3-wire
PHH-M0804N1-DF3-140 M8 4mm Non-flush NPN.NO 45mm Cable,2m,3-wire
PHH-M0804N2-DF3-140 M8 4mm Non-flush NPN.NC 45mm Cable,2m,3-wire
PHH-M0804P1-DF3-140 M8 4mm Non-flush PNP.NO 45mm Cable,2m,3-wire
PHH-M0804P2-DF3-140 M8 4mm Non-flush PNP.NC 45mm Cable,2m,3-wire
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
POH-M1202N1-DF3-120 M12 2mm Flush NPN.NO 50mm Cable,2m,3-wire
POH-M1202N2-DF3-120 M12 2mm Flush NPN.NC 50mm Cable,2m,3-wire
POH-M1202P1-DF3-120 M12 2mm Flush PNP.NO 50mm Cable,2m,3-wire
POH-M1202P2-DF3-120 M12 2mm Flush PNP.NC 50mm Cable,2m,3-wire
PHH-M1204N1-DF3-120 M12 4mm Non-flush NPN.NO 50mm Cable,2m,3-wire
PHH-M1204N2-DF3-120 M12 4mm Non-flush NPN.NC 50mm Cable,2m,3-wire
PHH-M1204P1-DF3-120 M12 4mm Non-flush PNP.NO 50mm Cable,2m,3-wire
PHH-M1204P2-DF3-120 M12 4mm Non-flush PNP.NC 50mm Cable,2m,3-wire
POH-M1203N1-DF3-150 M12 3mm Flush NPN.NO 50mm Cable,2m,3-wire
POH-M1203N2-DF3-150 M12 3mm Flush NPN.NC 50mm Cable,2m,3-wire
POH-M1203P1-DF3-150 M12 3mm Flush PNP.NO 50mm Cable,2m,3-wire
POH-M1203P2-DF3-150 M12 3mm Flush PNP.NC 50mm Cable,2m,3-wire
POH-M1202N1-DF3-220 M12 2mm Flush NPN.NO 50mm Cable,2m,3-wire
POH-M1202N2-DF3-220 M12 2mm Flush NPN.NC 50mm Cable,2m,3-wire
POH-M1202P1-DF3-220 M12 2mm Flush PNP.NO 50mm Cable,2m,3-wire
POH-M1202P2-DF3-220 M12 2mm Flush PNP.NC 50mm Cable,2m,3-wire
PHH-M1204N1-DF3-150 M12 4mm Non-flush NPN.NO 50mm Cable,2m,3-wire
PHH-M1204N2-DF3-150 M12 4mm Non-flush NPN.NC 50mm Cable,2m,3-wire
PHH-M1204P1-DF3-150 M12 4mm Non-flush PNP.NO 50mm Cable,2m,3-wire
PHH-M1204P2-DF3-150 M12 4mm Non-flush PNP.NC 50mm Cable,2m,3-wire
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
POH-M1805N1-DF3-120 M18 5mm Flush NPN.NO 55mm Cable,2m,3-wire
POH-M1805N2-DF3-120 M18 5mm Flush NPN.NC 55mm Cable,2m,3-wire
POH-M1805P1-DF3-120 M18 5mm Flush PNP.NO 55mm Cable,2m,3-wire
POH-M1805P2-DF3-120 M18 5mm Flush PNP.NC 55mm Cable,2m,3-wire
PHH-M1808N1-DF3-120 M18 8mm Non-flush NPN.NO 55mm Cable,2m,3-wire
PHH-M1808N2-DF3-120 M18 8mm Non-flush NPN.NC 55mm Cable,2m,3-wire
PHH-M1808P1-DF3-120 M18 8mm Non-flush PNP.NO 55mm Cable,2m,3-wire
PHH-M1808P2-DF3-120 M18 8mm Non-flush PNP.NC 55mm Cable,2m,3-wire
POH-M1805N1-DF3-150 M18 5mm Flush NPN.NO 55mm Cable,2m,3-wire
POH-M1805N2-DF3-150 M18 5mm Flush NPN.NC 55mm Cable,2m,3-wire
POH-M1805P1-DF3-150 M18 5mm Flush PNP.NO 55mm Cable,2m,3-wire
POH-M1805P2-DF3-150 M18 5mm Flush PNP.NC 55mm Cable,2m,3-wire
PHH-M1808N1-DF3-150 M18 8mm Non-flush NPN.NO 55mm Cable,2m,3-wire
PHH-M1808N2-DF3-150 M18 8mm Non-flush NPN.NC 55mm Cable,2m,3-wire
PHH-M1808P1-DF3-150 M18 8mm Non-flush PNP.NO 55mm Cable,2m,3-wire
PHH-M1808P2-DF3-150 M18 8mm Non-flush PNP.NC 55mm Cable,2m,3-wire
POH-M1805N1-DF3-230 M18 5mm Flush NPN.NO 55mm Cable,2m,3-wire
POH-M1805N2-DF3-230 M18 5mm Flush NPN.NC 55mm Cable,2m,3-wire
POH-M1805P1-DF3-230 M18 5mm Flush PNP.NO 55mm Cable,2m,3-wire
POH-M1805P2-DF3-230 M18 5mm Flush PNP.NC 55mm Cable,2m,3-wire
PHH-M1808N1-DF3-230 M18 8mm Non-flush NPN.NO 55mm Cable,2m,3-wire
PHH-M1808N2-DF3-230 M18 8mm Non-flush NPN.NC 55mm Cable,2m,3-wire
PHH-M1808P1-DF3-230 M18 8mm Non-flush PNP.NO 55mm Cable,2m,3-wire
PHH-M1808P2-DF3-230 M18 8mm Non-flush PNP.NC 55mm Cable,2m,3-wire
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
POH-M3010N1-DF3-180 M30 10mm Flush NPN.NO 55mm Cable,2m,3-wire
POH-M3010N2-DF3-180 M30 10mm Flush NPN.NC 55mm Cable,2m,3-wire
POH-M3010P1-DF3-180 M30 10mm Flush PNP.NO 55mm Cable,2m,3-wire
POH-M3010P2-DF3-180 M30 10mm Flush PNP.NC 55mm Cable,2m,3-wire
PHH-M3015N1-DF3-180 M30 15mm Non-flush NPN.NO 55mm Cable,2m,3-wire
PHH-M3015N2-DF3-18 M30 15mm Non-flush NPN.NC 55mm Cable,2m,3-wire
PHH-M3015P1-DF3-180 M30 15mm Non-flush PNP.NO 55mm Cable,2m,3-wire
PHH-M3015P2-DF3-180 M30 15mm Non-flush PNP.NC 55mm Cable,2m,3-wire
POH-M3010N1-DF3-230 M30 10mm Flush NPN.NO 55mm Cable,2m,3-wire
POH-M3010N2-DF3-230 M30 10mm Flush NPN.NC 55mm Cable,2m,3-wire
POH-M3010P1-DF3-230 M30 10mm Flush PNP.NO 55mm Cable,2m,3-wire
POH-M3010P2-DF3-230 M30 10mm Flush PNP.NC 55mm Cable,2m,3-wire
PHH-M3015N1-DF3-230 M30 15mm Non-flush NPN.NO 55mm Cable,2m,3-wire
PHH-M3015N2-DF3-230 M30 15mm Non-flush NPN.NC 55mm Cable,2m,3-wire
PHH-M3015P1-DF3-230 M30 15mm Non-flush PNP.NO 55mm Cable,2m,3-wire
PHH-M3015P2-DF3-230 M30 15mm Non-flush PNP.NC 55mm Cable,2m,3-wire
