Inductive proximity sensor

Inductive full-metal 2-wire proximity sensors

 Stainless steel, standard two-wire technology

 High frequency, strong anti-interference

 IP67 protection rating

Industry application：Automobile industry / Packaging industry / Smart storage / Metallurgical Industry / Petrochemical / Printing industry / Machine tool industry / Textile industry / Food Industry / Factory automation

Basic Parameters

  • M12
  • M18
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
PHM-M1204D1-DP2 M12 4mm 1000Hz Non-flush NO 50mm Cable,2m,2-wire
PHM-M1204D2-DP2 M12 4mm 1000Hz Non-flush NC 50mm Cable,2m,2-wire
POM-M1202D1-DS1268 M12 2mm 2000Hz Flush NO 68mm Connector M12,4-pole
POM-M1202D2-DS1268 M12 2mm 2000Hz Flush NC 68mm Connector M12,4-pole
PHM-M1204D1-DS1268 M12 4mm 1000Hz Non-flush NO 68mm Connector M12,4-pole
PHM-M1204D2-DS1268 M12 4mm 1000Hz Non-flush NC 68mm Connector M12,4-pole
POM-M1202D1-DP2 M12 2mm 2000Hz Flush NO 50mm Cable,2m,2-wire
POM-M1202D2-DP2 M12 2mm 2000Hz Flush NC 50mm Cable,2m,2-wire
Model Photo Standard Sensing Range Swithing Frequency Mounting Type Output signa Product length Connection Types
POM-M1808D1-DP2 M18 8mm 2000Hz Flush NO 55mm Cable,2m,2-wire
POM-M1808D2-DP2 M18 8mm 2000Hz Flush NC 55mm Cable,2m,2-wire
PHM-M1816D1-DP2 M18 16mm 1000Hz Non-flush NO 55mm Cable,2m,2-wire
PHM-M1816D2-DP3 M18 16mm 1000Hz Non-flush NC 55mm Cable,2m,2-wire
POM-M1808D1-DS1279 M18 8mm 2000Hz Flush NO 79mm Connector M12,4-pole
POM-M1808D2-DS1279 M18 8mm 2000Hz Flush NC 79mm Connector M12,4-pole
PHM-M1816D1-DS1279 M18 16mm 1000Hz Non-flush NO 79mm Connector M12,4-pole
PHM-M1816D2-DS1279 M18 16mm 1000Hz Non-flush NC 79mm Connector M12,4-pole
